Hisaka HF5 Ball Valve 3/4" CL150 SCS13A, Two-Way, Full Bore, 2-Pieces, Fire-Safe Design
Hisaka HF5 Ball Valve 3/4" CL150 SCS13A, Two-Way, Full Bore, 2-Pieces, Fire-Safe Design
Brand:
HISAKA
Model:
HF5
Specifications
infotip-icon
View other Ball Valve dimensions or variations
Please select at least one specification below.
Connection Type
Flanged
Working Pressure
JIS10K
Valve Body Material
SCS13A
Flange Face
Raised Face (RF)
Specification Met
JIS Standards
Max Working Temperature
200
C
Size
3/4"
Connection Standard
JIS B2220
Blow-out Proof
YES
Fire Safety
API607-4th
Product Description

HISAKA Flanged Stainless Steel Ball Valve – #1 Japan's Valve Brand in Eezee!

Engineered with precision and built to Japanese standards, the HISAKA HF5 Ball Valve delivers reliable performance for industrial applications. Made from durable stainless steel (SCS13A), it supports high-temperature operation up to 200°C.

Cross Section of the Ball Valve
Cross Section of the Ball Valve
  1. MAXTITE PTFE ball seat for excellent chemical and high-temperature resistance
  2. Full bore for maximum flow
  3. Two-way flow type with flanged ends
  4. Triple PTFE gland packing layers for stable sealing
  5. JIS10K flange compatible
  6. Optional locking device keeps the valve safely locked in fully open or closed positions
  7. Fire-safe design with secondary metal seat and anti-blowout stem

1-year warranty for the ball valve set, excluding wear parts.

*Subject to terms and conditions.

________________________________________________________________

🚚 Delivery charges will be quoted separately.

For orders below 30kg:

  • West Malaysia: Flat rate of RM70
  • Labuan: Flat rate of RM200
  • Sabah & Sarawak: Delivery charges will vary depending on location
  • Free Trade Zone: Delivery charges may be vary due to restricted access and clearance procedures

For orders above 30kg, delivery charges may vary depending on weight and destination.

Stock ready in Malaysia – ships within 3 working days (ex-works, excluding delivery time)

RM 585.00
UnitsDiscountUnit Price
1-RM 585.00
Quantity:
EA
Stock:
10 EA in stock
location
In Seller's Warehouse
Lead time of 3 working days required.
Item will be ready to dispatch within the lead time specified.
