Schneider Electric LC1E400U7 Contactor - Easypact Tvs - 3P (3 No) - AC-3 - <= 440 V 400 a - 240 V Ac Coil
Schneider Electric LC1E400U7 Contactor - Easypact Tvs - 3P (3 No) - AC-3 - <= 440 V 400 a - 240 V Ac Coil
Product Description

Schneider Electric LC1E400U7 Contactor - Easypact Tvs - 3P (3 No) - AC-3 - <= 440 V 400 a - 240 V Ac Coil

  • Type: 3 poles for motor applications
  • Rated Current: Up to 400A
  • Power Rating: 250 kW @ 440V
  • Coil Voltage: 240V AC (50/60Hz)
  • Auxiliary Contacts: None
  • Connections: Power and control via screw clamp terminals
  • Width: 213mm
  • Operating Rate: Up to 2400 cycles/hour
  • Durability:
    • Electrical: 0.6 million cycles (AC-3)
    • Mechanical: 4 million cycles
  • Temperature Range: -5°C to 55°C
  • Mounting: DIN-rail mountable
  • Altitude: No derating up to 3000m
  • Certifications: Multi-standard certified (IEC, CCC, EAC)
  • Environmental Compliance: Green Premium compliant (RoHS/REACH)

This contactor is engineered for high-performance motor control in demanding industrial settings, ensuring reliable operation and durability.
