Circuit Breakers
Circuit Trips
Circuit Trips
Circuit Trips
Device Short Name
MX
iMX
MX + OF
iMX+OF
MX
iMX
Range
Compact
ComPacT NSX100...250
ComPacT NSX400...630
ComPact NSX
Compact
ComPacT NSX100...250
Range Of Product
EZC100
ComPacT NSXm new generation
Acti9
EZCV250 EZC250
EZC100
ComPacT NSXm new generation
[Uc] Control Circuit Voltage
220...240 V AC 50 Hz 208...240 V AC 60 Hz
12...24 V AC 50/60 Hz 12...24 V DC
200...240 V AC 50/60 Hz
200...277 V AC 50/60 Hz
220...240 V AC 50 Hz 208...240 V AC 60 Hz
12...24 V AC 50/60 Hz 12...24 V DC
Range Compatibility
Acti 9 Acti9 iC65 Acti 9 Acti9 ARA Acti 9 Acti9 iDPN Vigi Acti 9 Acti9 iID Acti 9 Acti9 iSW-NA Acti 9 Acti9 RCA Acti 9 Acti9 iDPN (China version) Acti 9 Acti9 iC60 Acti 9 Acti9 iC40
Acti 9 Acti9 iDPN Acti 9 Acti9 C120 Acti 9 Acti9 C40 Acti 9 Acti9 C60H-DC Acti 9 Acti9 C60NA-DC Acti 9 Acti9 C60PV-DC Acti 9 Acti9 DPN Vigi Acti 9 Acti9 DT40 Acti 9 Acti9 DT60 Acti 9 Acti9 ID C40 Acti 9 Acti9 IDc Acti 9 Acti9 ITG40 Acti 9 Acti9 ID Acti 9 Acti9 DPN
EasyPact EasyPact EZC
Acti 9 Acti9 iC65 Acti 9 Acti9 ARA Acti 9 Acti9 iDPN Vigi Acti 9 Acti9 iID Acti 9 Acti9 iSW-NA Acti 9 Acti9 RCA Acti 9 Acti9 iDPN (China version) Acti 9 Acti9 iC60 double terminals miniature circuit breaker Acti 9 Acti9 iC40
Acti 9 Acti9 iC65 Acti 9 Acti9 ARA Acti 9 Acti9 iDPN Vigi Acti 9 Acti9 iID Acti 9 Acti9 iSW-NA Acti 9 Acti9 RCA Acti 9 Acti9 iDPN (China version) Acti 9 Acti9 iC60 Acti 9 Acti9 iC40
Acti 9 Acti9 iDPN Acti 9 Acti9 C120 Acti 9 Acti9 C40 Acti 9 Acti9 C60H-DC Acti 9 Acti9 C60NA-DC Acti 9 Acti9 C60PV-DC Acti 9 Acti9 DPN Vigi Acti 9 Acti9 DT40 Acti 9 Acti9 DT60 Acti 9 Acti9 ID C40 Acti 9 Acti9 IDc Acti 9 Acti9 ITG40 Acti 9 Acti9 ID Acti 9 Acti9 DPN
Miniature Circuit Breakers - MCBs
Miniature Circuit Breakers - MCBs
Miniature Circuit Breakers - MCBs
[In] Rated Current
8 A
3 A
20 A
35 A
8 A
3 A
Breaking Capacity
20 kA, 15 kA
10 kA
15 kA
7.5 kA
20 kA, 15 kA
10 kA
Standards
EN 60947-2 IEC 60898-1 IEC 60947-2 EN 60898-1
EN 60898-1 IEC 60947-2 IEC 60898-1 EN 60947-2
IEC 60947-2 IEC 60898-1 EN 60947-2 EN 60898-1
EN 60898-1 IEC 60898-1 EN 60947-2 IEC 60947-2
EN 60947-2 IEC 60898-1 IEC 60947-2 EN 60898-1
EN 60898-1 IEC 60947-2 IEC 60898-1 EN 60947-2
Magnetic Tripping Limit
10...14 x In
12 x In +/- 20 %
3...5 x In
8 x In +/- 20 %
10...14 x In
12 x In +/- 20 %
[In] Rated Current
8 A
3 A
20 A
35 A
8 A
3 A
