Pilot Lights

Standards

IEC 60947-5-1 IEC 60947-1 UL 508 JIS C8201-5-1 CSA C22.2 No 14 JIS C8201-1

IEC 60947-1 CSA C22.2 No 14 JIS C8201-5-1 UL 508 IEC 60947-5-1 JIS C8201-1

IEC 60947-5-1 IEC 60947-1 JIS C8201-5-1 CSA C22.2 No 14 UL 508 JIS C8201-1

CSA C22.2 No 14 UL 508 IEC 60947-5-1 IEC 60947-1 JIS C8201-5-1 JIS C8201-1

IEC 60947-5-1 IEC 60947-1 UL 508 JIS C8201-5-1 CSA C22.2 No 14 JIS C8201-1

IEC 60947-1 CSA C22.2 No 14 JIS C8201-5-1 UL 508 IEC 60947-5-1 JIS C8201-1

Connections - terminals

Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to IEC 60947-1

Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to IEC 60947-1

Faston connectors, connection size: 2.8 x 0.5 mm

Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1

Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to IEC 60947-1

Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to IEC 60947-1

IP Degree of Protection

IP20 (rear face) conforming to IEC 60529 IP54 (front face) conforming to IEC 60529

IP65

IP66, IP67

IP20, IP65

IP20 (rear face) conforming to IEC 60529 IP54 (front face) conforming to IEC 60529

IP65

[Us] Rated Supply Voltage

230...240 V AC 50/60 Hz

12...24 V AC/DC

110...120 V AC at 50/60 Hz

24 V AC/DC 50/60 Hz

230...240 V AC 50/60 Hz

12...24 V AC/DC

Cap/Operator Or Lens Colour

Red

Yellow

Blue

Clear

Red

Yellow
